| Numar porturi |
24x RJ-45
|
| Porturi |
24x RJ45
4x 10Gb 1x Console |
| Viteza de transfer |
10/100/1000 Mbps
|
| Management |
Da
|
| Putere consumata |
465.8 W
|
| Alimentare |
100 – 240VAC, 50/60Hz
|
| Dimensiuni |
440 x 330 x 44 mm
|
| Montare in rack |
Da
|
| Functii LED |
Link / Act
|
| Adrese MAC |
16 K
|
| LAN-Port-Type | Gigabit |
|---|---|
| Management | Managed |
| PoE | Da |
| Storage temperature (T-T) | -40 – 70 °C |
| Storage relative humidity (H-H) | 5 – 90% |
| Product colour | Black |
| Quick start guide | Yes |
| Operating temperature (T-T) | 0 – 45 °C |
| LED indicators | Yes |
| Jumbo frames support | Yes |
| Link aggregation | Yes |
| Cables included | LAN (RJ-45) |
| Height | 44 mm |
| Power supply included | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Operating relative humidity (H-H) | 10 – 90% |
| AC input voltage | 100 – 240 V |
| Power over Ethernet (PoE) | Yes |
| Number of fans | 2 fan(s) |
| Depth | 330 mm |
| Rack mounting | Yes |
| VLAN support | Yes |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| System event log | Yes |
| Switch type | Managed |
| 10G support | Yes |
| Port mirroring | Yes |
| Form factor | 1U |
| Policy-based routing | Yes |
| Access Control List (ACL) | Yes |
| Width | 440 mm |
| Flow control support | Yes |
| Rate limiting | Yes |
| IGMP snooping | Yes |
| Power source | AC |
| Installed SFP modules quantity | 0 |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Gigabit Ethernet (copper) ports quantity | 24 |
| Broadcast storm control | Yes |
| Spanning tree protocol | Yes |
| Multicast support | Yes |
| Jumbo frames | 9000 |
| Active link detection | Yes |
| Number of VLANs | 4000 |
| MAC address table | 16000 entries |
| Switching capacity | 128 Gbit/s |
| SSH/SSL support | Yes |
| Loop protection | Yes |
| Cloud-managed | Yes |
| BPDU filtering/protection | Yes |
| Power connector | AC-in jack |
| Packet buffer memory | 12 MB |
| Head-of-line (HOL) blocking | Yes |
| Virtual LAN features | MAC address-based VLAN, Port-based VLAN, Private VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN |
| Number of static routes | 48 |
| DHCP features | DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 snooping |
| IP-MAC-Port binding | Yes |
| Management protocols | SNMPv1/v2c/v3, SNTP |
| MIB support | Yes |
| Power over Ethernet plus (PoE+) ports quantity | 24 |
| Forwarding rate | 95.23 Mpps |
| Power consumption (max) | 486.2 W |
| Heat dissipation | 1658.78 BTU/h |
| Total Power over Ethernet (PoE) budget | 384 W |
| Networking standards | IEEE 802.11d, IEEE 802.1s, IEEE 802.1w |
| Porturi RJ 45 | 24-28 |
| Viteza Transfer | Gigabit |
| Porturi SFP | 3-4 |
| Montare in Rack | Da |
| SFP module slots quantity | 4 |
| Console port | RJ-45/micro-USB |
| AC input frequency | 50-60 Hz |
| Producator | TP-LINK |
| Garantie | 60 |
