Numar porturi |
8x RJ-45
|
Viteza de transfer |
10/100/1000 Mbps
|
Management |
Da
|
Putere consumata |
6.42 W
|
Alimentare |
100 – 240VAC, 50/60Hz
|
Dimensiuni |
209 x 126 x 26 mm
|
Adrese MAC |
8K
|
Metoda forwarding |
11.9 Mpps
|
Routing/Switch Fabric |
16 Gbps
|
Standarde |
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x
|
Altele |
VLAN 802.1q , STP/RSTP/MSTP, LACP
|
Management | Smart managed |
---|---|
PoE | Nu |
LAN-Port-Type | Gigabit |
Storage temperature (T-T) | -40 – 70 °C |
Storage relative humidity (H-H) | 5 – 90% |
Height | 26 mm |
Product colour | Black |
Certification | CE/FCC/RoHS |
LED indicators | Yes |
Operating temperature (T-T) | 0 – 40 °C |
Jumbo frames support | Yes |
Link aggregation | Yes |
Power supply included | Yes |
User guide | Yes |
Operating relative humidity (H-H) | 10 – 90% |
Cables included | AC |
Package depth | 280 mm |
AC input voltage | 100 – 240 V |
Package height | 68 mm |
Depth | 126 mm |
Full duplex | Yes |
VLAN support | Yes |
Quality of Service (QoS) support | Yes |
Web-based management | Yes |
System event log | Yes |
Switch type | Managed |
Port mirroring | Yes |
Access Control List (ACL) | Yes |
Power over Ethernet (PoE) | No |
Width | 209 mm |
Switch layer | L2 |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Flow control support | Yes |
Package width | 223 mm |
Rate limiting | Yes |
IGMP snooping | Yes |
Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
Power source | AC |
Installed SFP modules quantity | 0 |
10G support | No |
Half duplex | Yes |
Broadcast storm control | Yes |
Spanning tree protocol | Yes |
Multicast support | Yes |
MAC address table | 8000 entries |
Jumbo frames | 9216 |
Fanless | Yes |
SSH/SSL support | Yes |
MIB support | Y |
Packet buffer memory | 4 MB |
DHCP features | DHCP client |
Cable types supported | Cat3, Cat4, Cat5, Cat5e |
Gigabit Ethernet (copper) ports quantity | 8 |
Switching capacity | 16 Gbit/s |
Forwarding rate | 11.9 Mpps |
Virtual LAN features | Multicast VLAN, Tagged VLAN, Voice VLAN |
Number of VLANs | 512 |
Security algorithms | SSH, SSH-2, SSL/TLS |
Power consumption (max) | 6.42 W |
Package weight | 930 g |
Porturi RJ 45 | 5-10 |
Viteza Transfer | Gigabit |
Porturi SFP | N/A |
Montare in Rack | Nu |
Producator | TP-LINK |
Garantie | 24 |
