| Numar porturi |
8x RJ-45
|
| Porturi |
8x RJ45
|
| Viteza de transfer |
10/100/1000 Mbps
|
| Management |
Da
|
| Putere consumata |
65.2 W
|
| Alimentare |
DC 48V
|
| PoE |
Da, 4 porturi PoE
|
| PoE Budget |
55 W
|
| Dimensiuni |
158 x 101 x 25 mm
|
| Functii LED |
System/PWR, Link/Activity
|
| Memorie Buffer |
1.5 MB
|
| Adrese MAC |
4K
|
| Metoda forwarding |
11.9 Mpps
|
| Routing/Switch Fabric |
16 Gbps
|
| Standarde |
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p
|
| LAN-Port-Type | Gigabit |
|---|---|
| Management | Smart managed |
| PoE | Da |
| Storage temperature (T-T) | -40 – 70 °C |
| Package type | Box |
| Product colour | Black |
| Storage relative humidity (H-H) | 5 – 95% |
| Operating temperature (T-T) | 0 – 40 °C |
| Jumbo frames support | Yes |
| Link aggregation | Yes |
| Power supply included | Yes |
| User guide | Yes |
| Package width | 131 mm |
| Operating relative humidity (H-H) | 10 – 90% |
| Cables included | AC |
| Height | 25 mm |
| Package depth | 196 mm |
| Power over Ethernet (PoE) | Yes |
| Harmonized System (HS) code | 85176990 |
| Depth | 101 mm |
| VLAN support | Yes |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| Switch type | Managed |
| Port mirroring | Yes |
| Width | 158 mm |
| Switch layer | L2 |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Power source | DC |
| Auto MDI/MDI-X | Yes |
| IGMP snooping | Yes |
| Auto-negotiation | Yes |
| Installed SFP modules quantity | 0 |
| Certification | FCC, CE,Rohs |
| Package weight | 890 g |
| 10G support | No |
| Broadcast storm control | Yes |
| Cable types supported | Cat3, Cat4, Cat5, Cat5e, Cat6 |
| Packet buffer memory | 1.5 MB |
| Loop protection | Yes |
| Input current | 1.25 A |
| Power over Ethernet (PoE) ports quantity | 4 |
| Store-and-forward | Yes |
| Gigabit Ethernet (copper) ports quantity | 8 |
| Switching capacity | 16 Gbit/s |
| Forwarding rate | 11.9 Mpps |
| MAC address table | 4000 entries |
| Networking standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
| Virtual LAN features | Port-based VLAN |
| Number of VLANs | 32 |
| Jumbo frames | 15000 |
| LED indicators | Activity, Link, PoE, Power, Speed, Status |
| Input voltage | 48 V |
| Power consumption (max) | 65.2 W |
| Power over Ethernet (PoE) power per port | 15.4 W |
| Total Power over Ethernet (PoE) budget | 64 W |
| Heat dissipation | 256.19 BTU/h |
| Package height | 121 mm |
| Porturi RJ 45 | 5-10 |
| Viteza Transfer | Gigabit |
| Porturi SFP | N/A |
| Montare in Rack | Nu |
| Producator | TP-LINK |
| Garantie | 60 |
