| Numar porturi |
24x RJ-45
|
| Porturi |
24x RJ45
|
| Viteza de transfer |
10/100/1000 Mbps
|
| Putere consumata |
15.7 W
|
| Alimentare |
External 5 V/1,5 A Level “V” Power Adapter
|
| Dimensiuni |
257 x 178 x 46 mm
|
| Greutate |
760 g
|
| Functii LED |
Per port: Link/Activity/Speed
Per device: Power |
| Memorie Buffer |
128KB
|
| Adrese MAC |
8K
|
| LAN-Port-Type | Gigabit |
|---|---|
| Storage relative humidity (H-H) | 5 – 95% |
| Jumbo frames support | Yes |
| Power supply included | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Pallet gross width | 120 cm |
| Number of fans | 0 fan(s) |
| Pallet gross length | 110 cm |
| Full duplex | Yes |
| Rack mounting | Yes |
| Quality of Service (QoS) support | Yes |
| Form factor | 1U |
| Power over Ethernet (PoE) | No |
| Switch layer | L2 |
| Auto MDI/MDI-X | Yes |
| Flow control support | Yes |
| Number of power supply units | 1 |
| Auto-negotiation | Yes |
| Redundant power supply (RPS) support | No |
| Installed SFP modules quantity | 0 |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Gigabit Ethernet (copper) ports quantity | 24 |
| 10G support | No |
| Half duplex | Yes |
| Number of queues | 8 |
| MAC address table | 8000 entries |
| Switch type | Unmanaged |
| Jumbo frames | 9216 |
| Store-and-forward | Yes |
| Copper ethernet cabling technology | 1000BASE-T, 100BASE-TX, 10BASE-T |
| Networking standards | IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| Switching capacity | 48 Gbit/s |
| Forwarding rate | 35.71 Mpps |
| Packet buffer memory | 0.512 MB |
| Mean time between failures (MTBF) | 302287 h |
| Heat dissipation | 52.54 BTU/h |
| Shipping (inner) case height | 27 cm |
| Shipping (inner) case width | 41.3 cm |
| Shipping (inner) case length | 46.3 cm |
| Shipping (inner) case net weight | 11.5 kg |
| Pallet gross weight (air) | 373.6 kg |
| Products per pallet (air) | 140 pc(s) |
| Pallet height (air) | 2.02 m |
| Pallet gross weight (sea) | 373.6 kg |
| Master (outer) cases per pallet (sea) | 28 pc(s) |
| Products per pallet (sea) | 140 pc(s) |
| Pallet height (sea) | 2.02 m |
| Shipping (inner) case gross weight | 12.4 kg |
| Porturi RJ 45 | 24-28 |
| Viteza Transfer | Gigabit |
| Porturi SFP | N/A |
| Montare in Rack | Nu |
| Management | Nu |
| PoE | Nu |
| Producator | D-LINK |
| Garantie | 24 |
