| Numar porturi |
16x RJ-45
|
| Porturi |
16x RJ45
|
| Viteza de transfer |
10/100/1000 Mbps
|
| Putere consumata |
9 W
|
| Alimentare |
External 5 V/1 A Level “V” Power Adapter
|
| Dimensiuni |
231 x 158 x 46 mm
|
| Greutate |
580 g
|
| Functii LED |
Per port: Link/Activity/Speed
Per device: Power |
| Memorie Buffer |
128KB
|
| Adrese MAC |
8K
|
| LAN-Port-Type | Gigabit |
|---|---|
| Storage temperature (T-T) | -40 – 70 °C |
| Product colour | Black |
| Storage relative humidity (H-H) | 5 – 95% |
| Package width | 180 mm |
| LED indicators | Yes |
| Operating temperature (T-T) | 0 – 40 °C |
| Jumbo frames support | Yes |
| Height | 44 mm |
| Housing material | Metal |
| Power supply included | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Operating relative humidity (H-H) | 10 – 90% |
| Pallet gross width | 120 cm |
| Input current | 1 A |
| Number of fans | 0 fan(s) |
| Depth | 126 mm |
| Package height | 108 mm |
| Weight | 870 g |
| Harmonized System (HS) code | 85176990 |
| Pallet gross length | 110 cm |
| Products per shipping (inner) case | 10 pc(s) |
| Full duplex | Yes |
| Rack mounting | Yes |
| Quality of Service (QoS) support | Yes |
| Form factor | 1U |
| Power connector | DC-in jack |
| Power over Ethernet (PoE) | No |
| Switch layer | L2 |
| Auto MDI/MDI-X | Yes |
| Flow control support | Yes |
| Width | 280 mm |
| Products per pallet (air) | 300 pc(s) |
| Pallet height (sea) | 2.06 m |
| Number of power supply units | 1 |
| DC input voltage | 12 V |
| Auto-negotiation | Yes |
| Redundant power supply (RPS) support | No |
| Installed SFP modules quantity | 0 |
| 10G support | No |
| Half duplex | Yes |
| Number of queues | 8 |
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| MAC address table | 8000 entries |
| Switch type | Unmanaged |
| Switching capacity | 32 Gbit/s |
| Jumbo frames | 9216 |
| Gigabit Ethernet (copper) ports quantity | 16 |
| Store-and-forward | Yes |
| Copper ethernet cabling technology | 1000BASE-T, 100BASE-TX, 10BASE-T |
| Networking standards | IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| Packet buffer memory | 0.512 MB |
| Certification | CE Class A, FCC Class A, VCCI Class A, BSMI, CCC UL, CB, LVD, BSMI, CCC |
| Shipping (inner) case gross weight | 15.6 kg |
| Forwarding rate | 23.81 Mpps |
| Package depth | 328 mm |
| Master (outer) cases per pallet (sea) | 30 pc(s) |
| Pallet height (air) | 2.06 m |
| Shipping (inner) case height | 38.4 cm |
| Mean time between failures (MTBF) | 305171 h |
| Power consumption (max) | 11.7 W |
| Heat dissipation | 39.92 BTU/h |
| Package weight | 1.45 kg |
| Shipping (inner) case width | 34 cm |
| Shipping (inner) case length | 56.9 cm |
| Shipping (inner) case net weight | 15 kg |
| Pallet gross weight (air) | 491.5 kg |
| Pallet gross weight (sea) | 491.5 kg |
| Products per pallet (sea) | 300 pc(s) |
| Porturi RJ 45 | 11-18 |
| Viteza Transfer | Gigabit |
| Porturi SFP | N/A |
| Montare in Rack | Nu |
| Management | Nu |
| PoE | Nu |
| Producator | D-LINK |
| Garantie | 24 |
