“JetStream™ 48-Port Gigabit L2+ Managed Switch with 4 10GE SFP+ Slots PORT: 48× Gigabit RJ45 Ports, 4× 10G SFP+ Slots, RJ45/Micro-USB Console Port SPEC: 1U 19-inch Rack-mountable Steel Case FEATURE: Integration with JetStream™ SDN Controller, Static Routing, OAM, sFlow, DDM, 802.1Q VLAN, QinQ, STP/RSTP/MSTP, IGMP Snooping, 802.1p/DSCP QoS, ACL, 802.1x, Radius/Tacacs+ Authentication, LACP, CLI, SNMP, Dual Image/Configuration, IPv6”
| Management | Managed |
|---|---|
| PoE | Da |
| LAN-Port-Type | Gigabit |
| Storage temperature (T-T) | -40 – 70 °C |
| Storage relative humidity (H-H) | 5 – 90% |
| Package type | Box |
| Product colour | Black |
| Certification | CE/FCC/RoHS |
| Quick start guide | Yes |
| Operating temperature (T-T) | 0 – 45 °C |
| Password protection | Yes |
| LED indicators | Yes |
| Jumbo frames support | Yes |
| Link aggregation | Yes |
| Height | 44 mm |
| Power supply included | Yes |
| Operating relative humidity (H-H) | 10 – 90% |
| Cables included | AC |
| AC input voltage | 100 – 240 V |
| Number of fans | 0 fan(s) |
| Depth | 220 mm |
| Rack mounting | Yes |
| VLAN support | Yes |
| Quality of Service (QoS) support | Yes |
| Static route | Yes |
| Web-based management | Yes |
| System event log | Yes |
| Switch type | Managed |
| 10G support | Yes |
| Port mirroring | Yes |
| Form factor | 1U |
| MAC address filtering | Yes |
| Access Control List (ACL) | Yes |
| Power over Ethernet (PoE) | No |
| Width | 440 mm |
| Flow control support | Yes |
| Rate limiting | Yes |
| IGMP snooping | Yes |
| IGMP proxy | Yes |
| Rack mount kit | Yes |
| Power source | AC |
| Installed SFP modules quantity | 0 |
| Configuring Location Settings (CLI) | Yes |
| Broadcast storm control | Yes |
| Spanning tree protocol | Yes |
| Multicast support | Yes |
| Jumbo frames | 9000 |
| Number of VLANs | 4000 |
| MAC address table | 16000 entries |
| SSH/SSL support | Yes |
| Loop protection | Yes |
| GARP VLAN Registration Protocol (GVRP) | Yes |
| Cloud-managed | Yes |
| Basic switching RJ-45 Ethernet ports quantity | 48 |
| ARP inspection | Yes |
| BPDU filtering/protection | Yes |
| Switching capacity | 176 Gbit/s |
| Power connector | AC-in jack |
| Packet buffer memory | 12 MB |
| Head-of-line (HOL) blocking | Yes |
| Static port security | Yes |
| Number of static routes | 48 |
| IP-MAC-Port binding | Yes |
| Queue scheduling algorithms | SP, WRR+SP, Weighted Round Robin (WRR) |
| Multicast Listener Discovery (MLD) snooping | Y |
| Management protocols | SNMPv1/v2c/v3, SNTP |
| Authentication type | AAA, RADIUS, TACACS+ |
| MIB support | RFC1213, RFC2233, RFC1643, RFC1493, RFC2674, RFC2819, RFC2021, RFC2620, RFC2618, |
| Public MIB | Y |
| Huawei-proprietary MIB | Y |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad |
| IPv4 routes | 48 |
| IPv6 routes | 48 |
| Virtual LAN features | Private VLAN, Tagged VLAN, VLAN mapping, Voice VLAN |
| Forwarding rate | 130.9 Mpps |
| DHCP features | DHCP client, DHCP relay, DHCP server |
| Authentication | Auto VLAN, Guest VLAN, MAC-based authentication, Port-based authentication |
| IPv4 & IPv6 features | IPv4/IPv6 access-control list (ACL), IPv6 Telnet, IPv6 ping, IPv6 tracert |
| Power consumption (max) | 32.72 W |
| Heat dissipation | 111.65 BTU/h |
| Rack rails | Yes |
| Porturi RJ 45 | 28+ |
| Viteza Transfer | Gigabit |
| Porturi SFP | 3-4 |
| Montare in Rack | Da |
| SFP module slots quantity | 4 |
| Console port | RJ-45/micro-USB |
| AC input frequency | 50-60 Hz |
| Producator | TP-LINK |
| Garantie | 60 |
