HPE ProLiant MicroServer Gen11 E-2434 4c 32GB-U 4LFF-NHP 2x4TB HDD

Lifecycle

• Obsolete Date 31-01-2027

Specifications

• Optical drive type Optional ODD Bay Kit, none included
• Processor core available 4 core
• Expansion slots 2 PCIe, for detailed descriptions reference the QuickSpecs
• Form factor Ultra Micro Tower
• Processor speed 3.40 GHz
• Power supply type 1x 180W External Power Adapter, Non-Redundant Power Supply
• Network controller 4x1Gbe embedded
• Infrastructure management HPE iLO6, dedicated iLO port included
• Processor cache 12 MB Intel® Smart Cache
• Security Trusted Platform Module (TPM) 2.0
• Warranty Server warranty includes 1-year parts, 1-year labor, and 1-year onsite support with next business day response. Warranty repairs may be accomplished using Customer Self Repair (CSR) parts. These parts fall into two categories: 1) Mandatory CSR parts are designed for easy replacement. A travel and labor charge will result when customers decline to replace a Mandatory CSR part, 2) Optional CSR parts are also designed for easy replacement but may involve added complexity. Customers may choose to have Hewlett Packard Enterprise replace Optional CSR parts at no charge. 3) A trained, authorized service engineer must service non-CSR parts. For more information, visit https://www.hpe.com/support.
• Processor number 1 processor included
• Weight 17.571 lb
• Product dimensions (metric) 37.7 x 46.7 x 25.54 cm
• Product dimensions (imperial) 14.84 x 18.39 x 10.05 in
• Weight 7.97 kg
• System fan features 1 non-redundant system fan shipped standard
• Included drives 2x HPE 4TB SATA 6G Business Critical 7.2K LFF RW 1-year Warranty Multi Vendor HDD
• Processor name Intel® Xeon® E-2434 (4 core, 3.40 GHz, 12 MB Intel® Smart Cache, 55W)
• Included memory 32 GB (1×32 GB UDIMM, 4800 MT/s)
• Memory type HPE DDR5 Standard Memory
• Storage controller Embedded Intel VROC SATA Software Raid

Quickspecs

• QuickSpecs
• QuickSpecs (PDF)
• QuickSpecs
• QuickSpecs (HTML)

Overview

Are you looking for a budget friendly server that can fit almost anywhere?  The HPE ProLiant MicroServer Gen11 delivers an affordable, compact yet powerful entry server that you can customize for on-premises or for hybrid cloud possibilities while still meeting the enterprise-class performance, security, reliability, and expandability standards of the rest of the HPE ProLiant enterprise class server portfolio.  With a mini tower design, place it flat or vertically or wall mounted, depending on customer environment. The latest Intel® Xeon® 6300-series, Intel® Xeon® E and Intel® Pentium® processors supported to deliver compute performance, increased memory capacity, as well as security and remote management into the server with HPE iLO silicon root of trust. The affordable starting price makes the HPE ProLiant MicroServer Gen11 a good value that has the networking and performance capacity to grow with your business as your needs and budget change over time.

What’s new

• Fast OS Boot with the M.2 slot (optional slot available on the optional dedicated HPE iLO/M.2/serial port kit).
• Support for HPE iLO6. HPE iLO remote server management support is now standard without the need of the additional module or activation key.
• Optional Serial Port (via the dedicated HPE iLO/M.2/serial port option kit).
• Two PCIe expansion slots with the new PCIe 5.0 support.
• The latest Intel® Xeon® 6300-series, Intel® Xeon® E-2400 and Intel® Pentium® Gold processors.
• Four 4400 MT/s HPE DDR5 UDIMMs, offering 16, 32 GB. Up to 128 GB memory capacity support.

Features

HPE ProLiant MicroServer Gen11 features iLO Silicon root of trust with server management to provide enhanced security, proven reliability and superb usability.

Two PCIe expansion slots with the PCIe 5.0 support provide reliable scalability.

Embrace remote server management with HPE iLO6

Small, Quiet and Uniquely Designed Servers Bring the User Experience to a New Level
Mini in Size yet still Powerful and Secure

The latest Intel Xeon 6300-series, Xeon E-2400 and Pentium Gold processors provide impressive performance.

Optional wall mount kit provides deployment flexibility.

Offer enterprise-grade security with TPM 2.0 embedded.

Proven, yet Reimagined for the Data-Driven Edge

With four 4400 MT/s HPE DDR5 UDIMMs, it offers 16, 32 GB. and up to 128 GB memory capacity support.

HPE ProLiant MicroServer Gen11 features fast setup with a unique form factor that is compact and ideal for small spaces.

HPE ProLiant MicroServer Gen11 is a powerful yet affordable server for your daily business workloads.

Media

HPE ProLiant MicroServer Gen11 for SMB

Why sacrifice power for space? The HPE ProLiant MicroServer Gen11 packs big server performance into a compact, whisper-quiet package. Perfect for tight office spaces, it’s the go-to solution for small businesses that demand enterprise-level power.

New HPE ProLiant MicroServer Gen11 | Chalk Talk

In this Chalk Talk, meet the new HPE ProLiant MicroServer Gen11 – mini in size yet still powerful and secure. It’s our most popular entry-level server. The video will also look at what''s new compared to the previous generation, workloads, and more.

HPE ProLiant MicroServer Gen11 Product Animation

HPE ProLiant MicroServer Gen11 animated hardware tour.

Compatible products

• HPE iLO Advanced 1-server License with 1yr Support on iLO Licensed Features
• HPE Mobile USB DVD-RW Optical Drive
• HPE 1TB SATA 6G Business Critical 7.2K LFF RW 1-year Warranty Multi Vendor HDD
• HPE 4TB SATA 6G Business Critical 7.2K LFF RW 1-year Warranty Multi Vendor HDD
• HPE Smart Array E208e-p SR Gen10 (8 External Lanes/No Cache) 12G SAS PCIe Plug-in Controller
• HPE MicroServer Gen10 SFF-NHP Converter Kit
• HPE iLO Advanced 1-server License with 3yr Support on iLO Licensed Features
• HPE RDX External Docking Station
• HPE iLO Advanced Electronic License with 1yr Support on iLO Licensed Features
• HPE iLO Advanced Electronic License with 3yr Support on iLO Licensed Features
• Intel I350-T4 Ethernet 1Gb 4-port BASE-T Adapter for HPE
• HPE 32GB microSD RAID 1 USB Boot Drive
• Broadcom BCM57416 Ethernet 10Gb 2-port BASE-T Adapter for HPE
• Broadcom BCM57412 Ethernet 10Gb 2-port SFP+ Adapter for HPE
• HPE 240GB SATA 6G Read Intensive SFF BC Multi Vendor SSD
• HPE 960GB SATA 6G Read Intensive SFF BC Multi Vendor SSD
• Broadcom BCM5719 Ethernet 1Gb 4-port BASE-T Adapter for HPE
• HPE 16GB (1x16GB) Single Rank x8 DDR5-4800 CAS-40-39-39 Unbuffered Standard Memory Kit
• HPE 32GB 2RX8 PC5-4800B-E STND KIT
• HPE ML30 G11 Serial Port iLO/M.2 Enable
• HPE RDX 500GB Removable Disk Cartridge
• HPE RDX 1TB Removable Disk Cartridge
• HPE RDX 2TB Removable Disk Cartridge
• HPE RDX 4TB Removable Disk Cartridge
• HPE Proliant DL/ML Install Service

Documents

• HPE ProLiant MicroServer Gen11
