Lifecycle
- Obsolete Date 31-01-2025
- End of support date 31-01-2029
Specifications
- Ports 16 ports
- Availability features Integrated redundant power supply
- Media types QSFP28
- Protocol supported Ethernet
- Encryption capability None
- Product dimensions (metric) 4.39 x 20 x 50.8 cm
- Port speed 100 Gbps
- Aggregate switch bandwidth 3.2 Tbps
- Weight 4.53 kg
- Software (optional) HPE SN2100M 100GbE 8p Upgrade E-LTU (Q2M94AAE)
- Form factor 1U half-width
- Product dimensions (imperial) 1.72 x 7.87 x 20 in
- Model availability 16 QSFP28 ports active
- Weight 10 lb
- Software (required) NVIDIA® Cumulus Linux®, NVIDIA® ONYX®, or no OS depending on SKU selection. Refer to SKU description for options available.
- Warranty 3-year parts, 3-year labor, 3-year onsite support coverage. For more warranty information refer to http://h20564.www2.hpe.com/hpsc/wc/public/home.
Quickspecs
Overview
How can you provide fast, reliable, and cost-effective connectivity in the data center with predictable performance and investment protection? HPE Storage Switch M-series SN2100M is ideal for modern server and storage networks. Supporting port speeds of 1, 10, 25, 40, 50, and 100 GbE, delivering predictable performance and zero packet loss at line-rate across each port and packet size. Enhanced for storage combined with efficient design, it provides enterprise-level performance with attractive economics and outstanding ROI. Networks built on HPE Storage SN2100M are fast, reliable, and scalable while also being affordable and easy to manage. It supports primary and secondary storage, providing consistently fair, fast, and low-latency connectivity even under heavy workloads or a mix of different port speeds. This makes them ideal for storage, hyperconverged infrastructure, financial services, and media and entertainment deployments.
What’s new
- The NVIDIA® Cumulus Linux® Network Operating System is now bundled with the HPE Storage Switch M-series SN2100M using SKU S2T76A
Features
Lossless Low-latency Connectivity at 100 GbE in a Half-width Form Factor
Introduces dynamic shared buffers and wire speed performance with no packet loss for predictable data delivery.
HPE Storage Switch M-series SN2100M provides high-port density in a single rack unit, allowing for higher capacity and efficiency, simplifying scale-out environments and saving on total cost of ownership (TCO). Unique breakout cables fan out individual switch ports to multiple device ports.
Enhanced for Storage and Hyperconverged Environments
Unleashes Flash Storage Performance
Designed to use less electric power than competing switches, with less than 95W, HPE Storage Switch M-series SN2100M provides one of the industry’s lowest power draws, producing less heat than competing products and allowing reduced OpEx cost.
Capable of forwarding complete capacity wire-rate performance with zero packet loss across ports concurrently at 100 GbE speeds while transferring data across both Layer 2 and Layer 3 networks.
Provides enough internal bandwidth that there is sufficient capacity to carry ports at 100 Gbps bandwidth concurrently. This allows the switches to avoid head-of-line blocking which can reduce overall performance and throughput.
Provides wire-rate performance with zero packet loss across frame sizes, avoiding any negative impact on applications that could occur with frame loss as unexpected packet loss is unacceptable in modern data centers, especially within a storage network.
HPE Storage Switch M-series SN2100M provides ultra-low latency of under 300 ns port-to-port. This is advantageous for flash storage, which moved latency from storage access to the network, as well as for the burst nature of today’s software-defined and cloud data centers traffic.
With unique form factors and port counts, these Ethernet switches allow two HPE Storage SN2100M units to be deployed side-by-side allowing for increased density, making it the ideal top-of-rack (ToR) switch.
Can be deployed to support 1/10 GbE ports and is designed to be able to evolve over time to support 25, 50, and 100 GbE speeds. This helps future-proof your network architecture and allows for implementing significant speed changes to the architecture over time.
HPE Storage Switch M-series SN2100M provides predictability within a storage network and consistent throughput regardless of the packet size being transferred, the mixture of ports which are sending data, and even within mixed speed environments.
Media
Redefine HPE Storage Networking
A wide range of storage area network products and solutions that meet any customer requirements for performance, cost, scalability, manageability and investment protection.
